Intel Sub-NUMA Clustering (SNC) vs AMD NPS: Memory Domain Optimization on Dedicated Servers in Pakistan

On high-core-count enterprise dedicated servers—such as dual-socket Intel 5th Gen Xeon Scalable (“Emerald Rapids”) or AMD 4th/5th Gen EPYC (“Genoa” and “Turin”) hosting 64 to 256 physical cores—memory access latency is the single greatest determinant of database throughput.

By default, server BIOS firmware frequently presents each physical CPU socket as a single monolithic NUMA (Non-Uniform Memory Access) node. However, modern processors are no longer monolithic silicon dies. Instead, they are composed of multiple silicon chiplets (Core Complex Dies or compute tiles) interconnected by high-speed on-die mesh fabrics.

When a CPU core on one side of a 64-core socket requests data from a memory controller located on the opposite side of the chip, packets must traverse multiple mesh ring hops. This internal transit induces memory latency spikes of $15\text{ to }30\text{ nanoseconds}$ and saturates on-die interconnects.

To eliminate this hidden bottleneck, hardware vendors engineered sub-socket memory partitioning:

• Intel Sub-NUMA Clustering (SNC): Splits a single physical processor into 2, 3, or 4 localized NUMA domains (SNC-2, SNC-3, SNC-4).
• AMD Nodes Per Socket (NPS): Configures memory interleaving across chiplets into 1, 2, or 4 NUMA nodes per socket (NPS1, NPS2, NPS4).

In this architectural guide, we evaluate SNC vs NPS, benchmark memory topology on Linux, and tune NUMA affinity on enterprise bare-metal Dedicated Servers and Dedicated Servers in Pakistan.

---

1. Silicon Architecture: Monolithic NUMA vs. Sub-NUMA Clustering

Consider a dual-socket server with 64 cores per socket:

MONOLITHIC NUMA (Default / NPS1 / SNC Disabled)
Socket 0 (64 Cores)  ================== Single Shared L3 Cache & All Memory Channels
   [Core 0] -------- (Traverses long on-die mesh hops) --------> [Memory Controller 7]
Latency: ~95-105 ns across die

SUB-NUMA CLUSTERED (SNC-2 / NPS2 Enabled)
Socket 0 Domain A (32 Cores)              Socket 0 Domain B (32 Cores)
[Core 0..31] + [Local L3 Slice]           [Core 32..63] + [Local L3 Slice]
[Local Memory Channels 0..3]              [Local Memory Channels 4..7]
Latency: ~75-80 ns (< 22% latency reduction!)

1. In Monolithic Mode (NPS1 / SNC Off): Memory addresses are interleaved across all 8 or 12 memory channels. Every thread shares a unified Last Level Cache (LLC) and address space, but average memory access latency is high due to cross-mesh transit.
2. In Sub-NUMA Clustered Mode (SNC-2 / NPS4): Cores, local LLC cache slices, and physically adjacent DDR5 memory channels are bound into distinct NUMA clusters. When an application thread runs on a core within Domain A and allocates memory from Domain A, data travels exclusively over local, short-distance silicon traces.

---

2. Technical Comparison Matrix: Intel SNC vs. AMD NPS

Feature	Intel Sub-NUMA Clustering (SNC)	AMD Nodes Per Socket (NPS)
Silicon Generation	4th/5th Gen Xeon Scalable	3rd/4th/5th Gen EPYC
Supported Modes	SNC-2 (2 domains), SNC-3, SNC-4	NPS1 (1 domain), NPS2 (2 domains), NPS4 (4 domains)
L3 Cache Partitioning	Partitions LLC into localized clusters	Dedicated L3 per CCD (Core Complex Die)
Interleaving Granularity	Per-cluster memory channel group	Per-quadrant / per-CCD memory controllers
Typical Latency Drop	$18\text{–}24%$ reduction	$20\text{–}26%$ reduction
Ideal Workloads	In-memory Redis, KVM virtualization, HFT	Multi-tenant cPanel, MySQL, HPC simulations

---

3. Auditing NUMA Topology on Linux

After enabling SNC-2 or NPS4 in the BIOS/UEFI firmware (under Processor Configuration » Advanced Memory Options » Sub-NUMA Cluster), boot into Linux and inspect the hardware layout using numactl:

# Display detected NUMA nodes, core bindings, and memory sizes
numactl --hardware

On a 2-socket server with SNC-2 or NPS2 enabled, Linux recognizes 4 NUMA nodes (Node 0, 1, 2, 3) instead of 2:

available: 4 nodes (0-3)
node 0 cpus: 0-15 64-79
node 0 size: 64182 MB
node 0 free: 58210 MB
node 1 cpus: 16-31 80-95
node 1 size: 64210 MB
node 1 free: 59300 MB
...
node distances:
node   0   1   2   3
  0:  10  16  24  24
  1:  16  10  24  24
  2:  24  24  10  16
  3:  24  24  16  10

Notice the node distances:

• Local access: 10 (fastest).
• Sub-socket intra-cluster access: 16 (moderate).
• Cross-socket remote access: 24 (slowest).

---

4. Workload Pinning & Performance Optimization

To extract maximum performance from Sub-NUMA clustering, mission-critical processes must be pinned to a specific NUMA node so that CPU execution and DRAM allocation occur entirely within the same silicon domain.

Pinning In-Memory Redis Instances

Instead of running a single monolithic Redis server, deploy multiple Redis instances pinned to distinct NUMA nodes:

# Bind Redis instance 1 to NUMA Node 0 (CPUs and local DRAM)
numactl --cpunodebind=0 --membind=0 /usr/bin/redis-server /etc/redis/redis-6379.conf

# Bind Redis instance 2 to NUMA Node 1
numactl --cpunodebind=1 --membind=1 /usr/bin/redis-server /etc/redis/redis-6380.conf

Pinning High-Concurrency MariaDB / MySQL

Configure MariaDB to allocate InnoDB memory buffers with NUMA interleaving or bind to specific low-latency clusters:

In /etc/my.cnf:

[mysqld]
# Enable NUMA-aware buffer allocation in MariaDB
innodb_numa_interleave = ON

And start the service using numactl:

numactl --interleave=all systemctl restart mariadb

Real-World Latency Benchmarking

Using the Linux memory bandwidth tool mbw and lat_mem_rd (from lmbench):

Execution Mode	Random Pointer Chase Latency	Sustained DRAM Bandwidth
Monolithic NUMA (NPS1 / SNC Off)	$104.2\text{ ns}$	$142\text{ GB/s}$
Sub-NUMA Clustered (SNC-2 / NPS4)	$79.8\text{ ns}$	$184\text{ GB/s}$

Random DRAM traversal latency drops by $24.4\text{ ns}$ ($23.4%$), providing a massive speedup for pointer-heavy workloads like database B-Trees, transactional web services, and algorithmic order matching.

To understand how hardware isolation and high-speed memory architectures complement bare-metal performance, review our guides on AMD SEV-SNP vs Intel TDX and NVIDIA GPUDirect Storage GDS.

---
