CSF Firewall Port Flood & SYN Flood Protection: cPanel DDoS Defense Guide

Small-to-medium Distributed Denial of Service (DDoS) attacks and malicious connection floods remain the most frequent cause of unplanned downtime on multi-tenant cPanel servers.

An attacker deploys a modest botnet or automated stressor tool targeting port 80 (HTTP) or port 443 (HTTPS). Within seconds, thousands of half-open TCP connections saturate the Linux kernel’s connection tracking table (nf_conntrack), exhausting the web server’s worker process pool (Apache MaxRequestWorkers or LiteSpeed connections). Legitimate visitors immediately experience 502 Bad Gateway or Connection Timed Out errors.

By properly tuning ConfigServer Security & Firewall (CSF) and leveraging the Linux kernel’s native iptables and SYN cookies, you can filter and drop flood attacks before they reach web server user-space.

---

Understanding TCP SYN Floods vs. Port Floods

Before editing configuration files, understand how each attack exhausts system resources:

TCP SYN FLOOD ATTACK (Layer 4 Protocol Exploit):
Attacker sends SYN Packet -> Server responds SYN-ACK -> Attacker NEVER sends ACK
  * Result: Server kernel reserves memory for half-open connection until timeout.
  * Fix: SYN Cookies and CSF SYNFLOOD iptables rate limiting.

PORT FLOOD ATTACK (Layer 7 Connection Exhaustion):
Attacker completes TCP handshake -> Spams 200 HTTP requests/second -> Ties up Apache worker
  * Result: Web server worker pool hits MaxRequestWorkers limit (Server 503/504).
  * Fix: CSF PORTFLOOD and Connection Tracking (CT_LIMIT) temporary IP drops.

---

Step 1: Configuring SYN Flood Protection in csf.conf

Connect to your server via SSH as root and edit /etc/csf/csf.conf (or navigate in WHM to Plugins >> ConfigServer Security & Firewall >> Firewall Configuration):

# Enable SYN Flood protection in iptables
SYNFLOOD = "1"

# The rate of SYN packets allowed per second across all ports
SYNFLOOD_RATE = "100/s"

# Maximum burst of SYN packets allowed before rate limiting activates
SYNFLOOD_BURST = "150"

Enabling Kernel-Level SYN Cookies

Ensure that the Linux kernel actively drops spoofed SYN packets by verifying /etc/sysctl.conf:

# Verify TCP syncookies are enabled
sysctl net.ipv4.tcp_syncookies
# Output should be: net.ipv4.tcp_syncookies = 1

# If set to 0, enable permanently:
echo "net.ipv4.tcp_syncookies = 1" >> /etc/sysctl.conf
sysctl -p

---

Step 2: Implementing Port Flood Throttling (PORTFLOOD)

PORTFLOOD restricts the number of new connections allowed to specific ports within a rolling time window. If an IP exceeds this threshold, CSF blocks the IP using iptables for a configured duration.

Syntax:

port;protocol;hits;interval;block_time

In /etc/csf/csf.conf, locate PORTFLOOD and configure:

# Throttle HTTP and HTTPS to maximum 50 connections within 5 seconds; block for 300 seconds (5 mins)
PORTFLOOD = "80;tcp;50;5;300,443;tcp;50;5;300"

Directives Explained:

• 80;tcp;50;5;300: If an IP opens more than 50 connections on port 80 within 5 seconds, drop all packets from that IP for 300 seconds.
• 443;tcp;50;5;300: Enforces the identical defense for encrypted TLS traffic.

---

Step 3: Connection Tracking Limits (CT_LIMIT)

Connection Tracking monitors the total number of simultaneous established connections per IP address across all ports:

# Check connections every 15 seconds
CT_INTERVAL = "15"

# Maximum simultaneous connections allowed from a single IP
CT_LIMIT = "300"

# Time to block an IP that exceeds CT_LIMIT (in seconds)
CT_BLOCK_TIME = "1800"

# Send email alert to root when an IP is blocked via CT
CT_EMAIL_ALERT = "0"

# Only track connections on specific critical ports
CT_PORTS = "80,443,21,22,25,110,143,465,587,993,995"

[!CAUTION] In Pakistan, setting CT_LIMIT below 200 can inadvertently block corporate offices or universities where hundreds of employees browse the internet through a single static public IP or cellular CGNAT pool. A threshold between 300 and 400 offers the ideal balance between DDoS mitigation and false-positive prevention.

---

Step 4: Whitelisting Cloudflare & Domestic Payment Webhooks

If your websites use Cloudflare as a reverse proxy, all incoming web traffic originates from Cloudflare’s IP ranges.

Without proper whitelisting, CSF’s PORTFLOOD and CT_LIMIT will view Cloudflare’s edge servers as an attacking botnet and block entire Anycast subnets, taking down every hosted site!

1. Download the official Cloudflare IP list:

# Add official Cloudflare IPv4 CIDRs to CSF ignore list
curl -s https://www.cloudflare.com/ips-v4 >> /etc/csf/csf.ignore

2. Similarly, ensure that Pakistani payment gateway webhook IP ranges (JazzCash, EasyPaisa, PayFast) are whitelisted in /etc/csf/csf.allow to prevent transaction callbacks from being dropped during flash sales.

---

Step 5: Applying Changes and Verifying CSF Status

After modifying configuration parameters, restart CSF and LFD (Login Failure Daemon):

# Restart CSF firewall rules
csf -r

# Restart LFD monitoring daemon
systemctl restart lfd

# Verify that SYN cookies and PORTFLOOD iptables chains are active
iptables -L -n -v | grep -i "PORTFLOOD"
